FEATURES
USER EXPERIENCE
The integrated topper now has a brightness control (high, medium, and low) allowing the FORCE to be customized to any environment. Arrows at the card and receipt slots light up to direct the user to those areas.
SERVICEABILITY
Our engineers added a light in the vault to make it easier to cash load and service the ATM. The new FORCE also gives maximum installation versatility with four power cord holes that allow machine to be placed anywhere.
SECURITY
The FORCE has an optional camera that photographs the user during transaction and stores it with the associated transaction record. It can also display the camera view on the transaction screen to make the user aware of being filmed. An additional camera mount is provided to allow installation of a third-party camera.
Full Specifications
- Microsoft Window® CE 7.0
- TCP/IP, Wireless, Dial-up
- 12.1” TFT LCD, Privacy filter (optional)
- 4×2 Touch Function Keys
- PCI compliant EPP
- T-DES
- DES
- RSA
- UL 291 Business Hours Safe (Level 1 option)
- Dip Hybrid Card Reader
- EMV Level 1,2 Compliant
- Anti-skimming (optional)
- 1,000 Notes Cassette
- 2,000 note removable cassette upgradable to three cassettes
- 80mm Graphical thermal receipt printer
- AC 110-240V
- 50-60 Hz
- Temperature: 41°F – 104°F (0° C ~ 40°C)
- Humidity: 25% – 85%
- Lead-through Indicator
- Audio Jack
- Speaker
- NFC (optional)
- Height: 56.4”
- Width: 15.7”
- Depth: 23.4”
- Weight: 286.6 lbs.
