FEATURES
Proven Cash Recycling
Reduce operating costs and increase availability
Small Footprint Design
Seamlessly install in any branch layout or location
Simplified Engineering
Efficient design ensures superior quality and maintenance
Selectable Cash Engine Configuration
Choose the cash recycling setup that best meets your needs
Full Specifications
- Height : 1,425mm (56.1″)
- Width : 470mm (18.5″)
- Depth : 1,000mm (39.4″)
- Weight : 332 kg (732 lbs)
- Temperature : 0°C ~ 40°C (32°F ~ 104°F)
- Humidity 25% – 85%
- Microsoft Windows® Platform
- Hyosung BlueVerse™ XFS
- 15” Touchscreen (19″ optional)
- Card reader (Dip or Motorized) – EMV compliant
- Contactless card reader
- Encrypted pin pad
- Audio jack
Bill Recycling Module
- 4 Recycling cassettes and 1 deposit cassette
- Recycling cassette: 314mm capacity
- Deposit Cassette: 330mm note capacity
- Dispense speed: 8 notes/sec
- Automatic shutter
- Bundle up to 200 notes per transaction
- Safe: UL291 Level-1
- Lock: E-lock + Key lock
- Sensor: Alarm (heat & seismic), 3 door sensors
- Privacy filter viewing angle 60°
- Anti-skimming, anti-shimming, anti-card trapping, anti-cash trapping
- Security camera (face & hand)
- BlueVerseSecurity software
- Front Access
- State of health indicators for all modules
- 3.1” graphical thermal receipt printer
- AC 100V ~ 240V±10% / Max 8.0A
- Backup battery (optional)
- Fingerprint scanner (optional)
- Barcode reader (optional)
- Selectable cash engine configuration
- Recycle up to 8 denominations
- Transit cassette function
